Vg Electric, Setup In The Year 1982 By Vishu Makhija To Cater The Requirements Of The Indian Industries For Electrical And Electronic Components Of World Class Quality. Vg Is Constantly On The Lookout For Latest Generation Good Quality Products For Its Customers. At Present Vg Represents: Moujen Electric Co. Ltd., Taiwan Tvs Sensing Solutions Pvt. Ltd. Gorlan India Switchgears Pvt. Ltd. The Products Range Includes: Micro Switches, Limit Switches, Push Button Switches, Pilot /Indicator Lights, Cam Operated Rotary Switches, On Load Change Over Switches, Dc Switch Disconnector, Breaker Control Switches, Sensors, Sensors, Etc.
View more
Our Leadership Team
Mr. vishmbhar makhija
Business Head
Products & Services
Me Mini Limit Switches
Product Detail
Me Mini Limit Switches
Compact limit switch in the metal case and in a variety of different control elements available. Simple installation and connection. IP65,-15 C to +70 C, 5A 250VAC Compact limit switch in metal enclosure. Available in a wide range of stainless steel actuators. Thanks to the integrated cable gland, the switch is easy CLOSE on. Maximum life span 10 million circuits with a maximum switching capacity of 5A 230 V / AC. With NO + NC contact equipped, IP65 sealing. At the customer’s pre-assembled cables with connectors deliver according to specification. Wide choice of heads and actuators. Variety of operating characteristics. Captive cover screws. Mode of operation is field adjustable. Internal grounding screw. Dustproof, Oil-Tight, Water-Resistant. Temperature range : +5 F to +160 F (-15 C to +70 C) FIELD ADJUSTABLE : Rotary motion roller lever and rod actuators are adjustable through 360. They may be set for operation clockwise, counter clockwise, or in both directions. Operating heads may be positioned in any of four 90 positions.
+ Show more
- Show less
Mvs Security Mini Switches
Product Detail
Mvs Security Mini Switches
MVS Security miniature switches. Transparante IP40 housing with NO / NC Snap-action contacts. NC contact with positive opening. Switching capacity of 6A-230V / AC. Faston Type 250 available, solder or screw terminals. Various types of actuating elements in stainless steel. FEATURES : Performance according to standards VDE0660, IEC/EN60947, UL508. Positive opening contact. Housing in PC transparent plastic and clear easily. Protection degree—IP40. Screw solder and #250 fasten terminal for choicing. CHARACTERISTICS : Operating speed 0.01 to 1m/sec Operating frequency mechanically 60 operations/min. Contact resistance 30m max Dielectric strength 1000 VAC, 50/60 Hz for 1 minute between non-continuous terminals. Operating temperature -40 C ~ +85 C Storage Humidity 85% RH max Service life mechanically: 10,000,000 circle. electrically: 5,000,000 operation, (1.5A, 110VAC)MAX. Protection Degree IP40
+ Show more
- Show less
Breaker Control Switch
Product Detail
Breaker Control Switch
GT Breaker Control Switch(BCS) is used to operate circuit breakers in a power circuit and in applications where frequent operations are required.BCS as it is popularly called is supplied with different combinations of contacts starting with basic configuration, 1 NO + 1 NC. GT Breaker Control Switch has three positions of switching namely TRIP,NEUTRAL & CLOSE.The handle comes back to the “NEUTRAL” position after making momentary contact on either side namely “TRIP & CLOSE”.This is made possible by the spring return mechanism.Thus BCS is essentially a spring return switch.BCS also incorporates sequence lock and lost motion device(LMD)
+ Show more
- Show less
M6 Push Button Switches
Product Detail
M6 Push Button Switches
Apparent shape Round (18mm) Square (18X18mm) Rectangular Square (18X24mm). Install and remove the contact block easily Gold-clad cross bar contact. Solder/plug-in terminal (#110) and P.C board terminal type. Light touch structure. Use of High Performance Engineering Plastics. protective grade : IP65 (IEC Pud 529)
+ Show more
- Show less
D4 Series
Product Detail
D4 Series
FEATURES : Current rating from 0.1amps to 21 amps @ 250 VAC Choice of actuators Various terminal type Choice of standard or light operating force VDE approved versions available upon request Stackable case and cover available upon request
+ Show more
- Show less
Rotary Cam Switch
Product Detail
Rotary Cam Switch
In a rotary cam switch,cams determine the function of the switch and since the switch achieves this by rotation it is called rotary cam switch.
+ Show more
- Show less
